Description
Original Dahua camera, firmware can be upgraded.
If you need a NVR , please click the product link below to order:
Support language:
English, Dutch, Italian, Spanish, French, German, Portuguese, Polish, Romanian, Hungarian, Czech, Russian, Hebrew, Arabic, Japanese, Korean, Turkish, Ukrainian, Thai, Indonesian, Vietnamese;
8MP Smart Dual Light Fixed-focal Eyeball WizSense Network Camera
> 8-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in warm light and IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Supports max. 256 G Micro SD card; built in MIC.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD Plus
Camera | |||||||||||
Image Sensor | 1/2.7″ CMOS | ||||||||||
Max. Resolution | 3840 (H) × 2160 (V) | ||||||||||
ROM | 128 MB | ||||||||||
RAM | 256 MB | ||||||||||
Scanning System | Progressive | ||||||||||
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||||||||
Min. Illumination | 0.008 [email protected] (Color, 30 IRE) | ||||||||||
0.0008 [email protected] (B/W, 30 IRE) | |||||||||||
0 lux (Illuminator on) | |||||||||||
S/N Ratio | >56 dB | ||||||||||
Illumination Distance | 30 m (98.43 ft) (IR); 30 m (98.43 ft) (Warm light) | ||||||||||
Illuminator On/Off Control | Auto; Manual | ||||||||||
Illuminator Number | 1 (IR LED); 1(Warm light) | ||||||||||
Pan/Tilt/Rotation Range | Pan: 0°–360° | ||||||||||
Tilt: 0°–78° | |||||||||||
Rotation: 0°–360° | |||||||||||
Lens | |||||||||||
Lens Type | Fixed-focal | ||||||||||
Lens Mount | M12 | ||||||||||
Focal Length | 2.8 mm; 3.6 mm | ||||||||||
Max. Aperture | F1.6 | ||||||||||
Field of View | 2.8 mm: H: 111°; V: 58°; D: 132° | ||||||||||
3.6 mm: H: 87°; V: 49°; D: 100° | |||||||||||
Iris Control | Fixed | ||||||||||
Close Focus Distance | 2.8 mm: 1.5 m (4.92 ft) | ||||||||||
3.6 mm: 1.9 m (6.23 ft) | |||||||||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||
2.8 mm | 84.8 m | 33.9 m | 17.0 m | 8.5 m | |||||||
(278.22 ft) | (111.22 ft) | (55.77 ft) | (27.89 ft) | ||||||||
3.6 mm | 98.7 m | 39.5 m | 19.7 m | 9.9 m | |||||||
(350.07 ft) | (129.59 ft) | (64.63 ft) | (32.48 ft) | ||||||||
Intelligence | |||||||||||
IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
||||||||||
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
||||||||||
Video | |||||||||||
Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) | ||||||||||
Smart Codec | Smart H.265+; Smart H.264+ | ||||||||||
Video Frame Rate | Main stream: 3840 × 2160 @(1–20 fps )/2688 × 1520@(1–25/30 fps) | ||||||||||
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) | |||||||||||
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
|||||||||||
Stream Capability | 2 streams | ||||||||||
Resolution | 3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 × 1728 (3072 × 1728); 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
||||||||||
Bit Rate Control | CBR/VBR | ||||||||||
Video Bit Rate | H.264: 32 kbps–8192 kbps | ||||||||||
H.265: 12 kbps–8192 kbps | |||||||||||
Day/Night | Auto(ICR)/Color/B/W | ||||||||||
BLC | Yes | ||||||||||
HLC | Yes | ||||||||||
WDR | 120 dB | ||||||||||
White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||||||||
Gain Control | Auto; Manual | ||||||||||
Noise Reduction | 3D NR | ||||||||||
Motion Detection | OFF/ON (4 areas, rectangular) | ||||||||||
Region of Interest (RoI) | Yes (4 areas) | ||||||||||
Smart Illumination | Yes | ||||||||||
Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688×1520 resolution and lower) | ||||||||||
Mirror | Yes | ||||||||||
Privacy Masking | 4 areas | ||||||||||
Audio | |||||||||||
Built-in MIC | Yes | ||||||||||
Audio Compression | G.711a; G.711Mu; PCM; G.726 | ||||||||||
Alarm | |||||||||||
Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception |
||||||||||
Network | |||||||||||
Network Port | RJ-45 (10/100 Base-T) | ||||||||||
SDK and API | Yes | ||||||||||
Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour |
||||||||||
Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone | ||||||||||
User/Host | 20 (Total bandwidth: 48 M) | ||||||||||
Storage | FTP; SFTP; Micro SD card (support max. 256 GB); NAS | ||||||||||
Browser | IE | ||||||||||
Chrome | |||||||||||
Firefox | |||||||||||
Management Software | Smart PSS; DSS; DMSS | ||||||||||
Mobile Client | iOS; Android | ||||||||||
Cyber Security | Configuration encryption; trusted execution; Digest; security logs; WSSE; account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification |
||||||||||
Certification | |||||||||||
Certifications | CE-LVD: EN62368-1 | ||||||||||
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU | |||||||||||
FCC: 47 CFR FCC Part 15, Subpart B | |||||||||||
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 | |||||||||||
Power | |||||||||||
Power Supply | 12 VDC/PoE (802.3af) | ||||||||||
Power Consumption | Basic: 2.6 W (12 VDC); 3.3 W (PoE) | ||||||||||
Max. (H.265+ max. resolution + max. stream+ WDR + warm light intensity + IVS): 5 W (12 VDC); 5.9 W (PoE) |
|||||||||||
Environment | |||||||||||
Operating Temperature | –40 °C to +55 °C (–40 °F to +131 °F) | ||||||||||
Operating Humidity | ≤95% | ||||||||||
Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||||||||
Storage Humidity | ≤95% | ||||||||||
Protection | IP67 | ||||||||||
Structure | |||||||||||
Casing Material | Inner core: Metal | ||||||||||
Cover: Plastic | |||||||||||
Product Dimensions | 100.9 mm × Φ109.9 mm (3.97″× Φ4.33″) | ||||||||||
Net Weight | 0.38 kg (0.84 lb) | ||||||||||
Gross Weight | 0.52 kg (1.15 lb) |
